FEATURES
- Powered by the NVIDIA Blackwell architecture and DLSS 4
- Powered by GeForce RTX™ 5060 Ti
- Integrated with 16GB GDDR7 128bit memory interface
- WINDFORCE cooling system
- Hawk fan
- Server-grade Thermal conductive gel
- RGB Lighting
- Dual BIOS (Performance / Silent)
- Reinforced structure
CORE CLOCK
2647 MHz (Reference card :2572 MHz)
REINFORCED STRUCTURE
The reinforced metal backplate with a bent edge, securely fastened to the I/O bracket, provides exceptional structural integrity.
DUAL BIOS (Performance / Silent)
The factory default setting is Performance mode, which provides users with the best performance. However, switching to Silent mode will enjoy a quieter experience.
POWER INDICATOR
-
Graphics ProcessingGeForce RTX™ 5060 Ti
-
Core Clock2647 MHz (Reference card :2572 MHz)
-
CUDA® Cores4608
-
Memory Clock28 Gbps
-
Memory Size16 GB
-
Memory TypeGDDR7
-
Memory Bus128 bit
-
Card BusPCI-E 5.0
-
Digital max resolution7680×4320
-
Multi-view4
-
Card sizeL=281 W=117 H=40 mm
-
PCB FormATX
-
DirectXDirectX 12 API
-
OpenGL4.6
-
Recommended PSU650W
-
Power Connectors8 Pin*1
-
OutputDisplayPort 2.1b *3
HDMI 2.1b *1 -
AccessoriesQuick guide
