Fractal Design Meshify 2 Compact RGB White TG Clear Tint

Availability:

Out of stock


฿4,990.00

Out of stock

Meshify 2 Compact RGB

The Meshify 2 Compact RGB is a high-performing case with a bold, stealth-inspired aesthetic. Its striking exterior features bolt-free, flush tempered glass, a fully removable top panel granting excellent interior access, and a front USB 3.1 Type-C port. The front nylon filter can be removed for extra airflow, letting the mesh front deal with filtering. Intelligent space utilization enables the Meshify 2 Compact to boast the performance and capacity of larger cases despite its remarkably compact mid-tower size, and the filtered airflow design makes cooling a breeze.

  • • Iconic angular mesh front provides filtered airflow with a bold, stealth-inspired aesthetic
  • • Versatile and space-efficient ATX form-factor design offers the performance and capacity of much larger cases
  • • Built in RGB controller on the front/top I/O with iconic Fractal Northern Lights effect

Refined airflow

  • Repositioned front fan mounting sets a wider stage for light and color
  • Install up to 7x 120 mm or 4x 140 mm fans (4x 120 mm Aspect 12 RGB PWM fans included)
  • Open interior layout creates a smooth airflow path from front intake to rear exhaust

Detachable front filter

  • Iconic angular mesh design provides filtered airflow with a bold, stealth-inspired aesthetic
  • Front nylon filter that can be removed for increased airflow
  • Easy-to-clean high airflow nylon filters on the front, top and base with full PSU coverage and convenient front access

Extremely flexible

  • Room for GPUs up to 360 mm with a 240 mm radiator in the top, or up to 360/280 mm front radiators with GPUs under 305 mm
  • Full length power supply shroud with two-part removable cover conceals drive cage and excess cabling for smooth airflow and a clean interior
  • Chassis opens up to fully expose the case interior on three sides for totally unhindered installation and cable routing

Bolt-free glass

  • Seamlessly integrated tempered glass panel with steel frame support and bolt-free top-latching mechanism
  • Flexible storage options supporting two 2.5”/3.5” drives and up to four SSDs (two SSD brackets included)
  • Seven bridgeless expansion slots ensure obstruction-free connections

Specifications

  • 3.5″/2.5″ Universal drive mounts
    2 (included)
  • Dedicated 2.5″ drive mounts
    4 (2 included)
  • Expansion slots
    7
  • Front interface
    1x USB 3.1 Gen 2 Type-C, 2x USB 3.0, Audio I/O, Power button, RGB control button (RGB Version only)
  • Total fan mounts
    7x 120 or 4x 140 mm and 2x 120 mm
  • Front fan
    3x 120 or 2x 140 mm, (3x Aspect 12 RGB PWM included)
  • Top fan
    2x 120/140 mm
  • Rear fan
    1x 120 mm, (1x Aspect 12 RGB PWM included)
  • Bottom fan
    1x 120 mm (requires removal of HDD cage)
  • Dust filters
    Top, front and bottom
  • Fixed cable straps
    Yes
  • Cable routing grommets
    Yes
  • Captive thumbscrews
    HDD, SSD and PSU brackets
  • Left side panel
    Tempered glass
  • Right side panel
    Steel

Compatibility

  • Motherboard compatibility
    ATX / mATX / Mini-ITX
  • Power supply type
    ATX
  • PSU max length
    165 mm (with HDD cage and front fan)
  • GPU max length
    345 mm
  • CPU cooler max height
    169 mm
  • Front radiator
    Up to 360/280 mm
  • Top radiator
    Up to 240 mm
  • Rear radiator
    120 mm
  • Bottom radiator
    120 mm (requires removal of HDD cage)
  • Cable routing space
    17-28 mm

Dimensions

  • Case dimensions (LxWxH)
    424 x 210 x 475 mm
  • Case dimensions w/o feet/protrusions/screws
    412 x 210 x 455 mm
  • Package dimensions (LxWxH)
    542 x 320 x 554 mm
  • Net weight
    8.5 KG
  • Gross weight
    9.8 KG
  • Volume
    41 liters

Other

  • Warranty
    2 Years
  • Package contents
    Meshify 2 Compact RGB Case, User manual, Accessory box
  • Product code
    White TG Clear tint: FD-C-MES2C-08



SKU: FD-C-MES2C-08 Categories: ,
