The Powerful Gaming and Streaming Desktop Processor
Get the competitive edge with the ultimate enthusiast processor for gamers, for creators, for everyone.
The latest technologies
The AMD Ryzen™ 9 is built to help you beat the clock, with features including PCIe® Gen5 connectivity, 12-cores and 24-threads, and support for dedicated video accelerators2.
The future of Ryzen
Power. Performance. Possibility. Utilising the new Socket AM5 architecture, motherboards deliver new features for gamers and creators, from the speed of DDR5 memory and AMD EXPO™ technology3 to increased bandwidth for graphics and storage with PCIe® Gen5.
AMD Ryzen™ 9 7900X
General Specifications
Platform Desktop
Product Family AMD Ryzen™ Processors
Product Line AMD Ryzen™ 9 Desktop Processors
# of CPU Cores 12
# of Threads 24
Max. Boost Clock Up to 5.6GHz
Base Clock 4.7GHz
L1 Cache 768KB
L2 Cache 12MB
L3 Cache 64MB
Default TDP 170W
Processor Technology for CPU Cores TSMC 5nm FinFET
Unlocked for Overclocking Yes
CPU Socket AM5
Thermal Solution (PIB) Not included
Max. Operating Temperature (Tjmax) 95°C
*OS Support
Windows 11 – 64-Bit Edition
Windows 10 – 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
Connectivity
Memory Channels 2
Max Memory Speed
1x1R 5200 MT/s
1x2R 5200 MT/s
2x1R 3600 MT/s
2x2R 3600 MT/s
Graphics Capabilities
Graphics Model AMD Radeon™ Graphics
Graphics Core Count 2
Graphics Frequency 2200 MHz
GPU Base 400 MHz
Key Features
Supported Technologies
AMD EXPO™ Technology
AMD Ryzen™ Technologies
